USB Duplicator and Sanitizer - Golden/Silver Series

High-speed duplication up to 16GB/min with advanced USB sanitization.

$500.00 CAD
$500.00 CAD
SKU: URCAUB905S
USB Duplicator and Sanitizer - Golden/Silver Series image 1 product photo
$500.00 CAD
$500.00 CAD

The most cutting-edge in duplication technology, our Intelligent 9 series USB duplicator is a professional, standalone and efficient equipment which can provide a full range of USB drive memory card duplicator starting from 9 and up to 119 targets. The speed and flexibility are the key factors to satisfy customer needs. Simplicity, no PC or other software are required; the USB drive memory card duplicator provides a reliable, worry-free copy environment for users without the risk of virus infection. This Intelligent 9 USB duplicator series is integrated with a high-speed compare function to ensure data copy with 100% accuracy along with quick format capabilities. This will greatly help increases efficiency and production productivity.

The Intelligent 9 Golden series has added some more important functions –Event Log Report, (6 Advantages from Event Log Report to Improve Your Duplication Management), Durability test and Double Source Comparison. Those functions are designed from professional users’ inquiry and help them to solve some critical issues from the duplication working process.

The Intelligent 9 USB drive memory card duplicator is an economical solution for data copy and distribution via USB drive memory card. It embeds smart and beneficial function and outstanding performance, reliable and quality that will save your time and money.



Features

    • Standalone, no PC required to operate the duplicator.
    • Compatible with the USB2.0/3.0/3.1/USB-HDD and other various USB devices.
    • Impeccable copy speed: up to 2 GB per min for each port and up to 120 ports.
    • Supports all types of data format copying while doing bit for bit duplication.
    • Supports “quick copy” for Linux (ext2/ext3/ext4) and NTFS, FAT16/32.
    • The USB stick can have a capacity up to largest size available on the market.
    • Supports 3TB and above capacity for external USB HDDs.
    • Support eUSB(USB-DOM) 2.54mm and 2.00mm (via adapter)
    • Supports log report for better production management.
    • Supports durability test.
    • Supports hardware-level write protection for USBs (contact us for details).

Overview

Intelligent Copy Option

The Intelligent 9 series USB drive memory card duplicator offers intelligent copy options to suit different needs. The Systems and Files mode enables copying only the data area, reducing the copy process duration. It supports various file formats such as Windows, Linux, and Mac. In cases where the file system format is not supported, the duplicator switches to the Whole Media copy mode, which copies the entire media.

Impeccable High Speed

With its advanced technology, the Intelligent 9 duplicator maintains impeccable high speeds even with multiple targets. It can copy up to 2GB per minute on all devices simultaneously, ensuring efficient duplication without speed degradation.

User-Friendly Design

The duplicator incorporates a user-friendly design for ease of use and convenience. It features modular sockets that allow for quick replacements, reducing downtime and cost in the long run. Additionally, its ergonomic and compact proportions reduce its size by 50% to 70% compared to traditional designs. The device also ensures high compatibilities with various USB devices, thanks to its unique redundant power design.

Quality Testing/Checking Functions

To ensure optimal performance and eliminate poor-quality USB drives, the Intelligent 9 series offers built-in quality testing and checking functions. These functions include read-only tests, capacity checks, write/read tests, read/write speed checks, quality tests, burn-in tests, and flash speed and capacity filtration. These tests help identify and remove subpar USB drives, ensuring reliable duplication.

Real-Time Monitoring and Event Log Report

The duplicator allows real-time monitoring via a PC connection, enabling users to keep track of the duplication process. Additionally, it generates an event log report that records the duplicator's operation, system, and target information. This report serves as a valuable tool for production quality control and yield analysis.

Intelligent U3 USB 3.0 Duplicator & Tester:
Specification:
Maximum Transfer Speed: 2GB/min. Actual performance is dependent on device transfer speeds.
Capacity: Supports the largest sized devices available on the market.
Operation Type: Stand-alone, FPGA-based operation (Non-PC based)
Language Support: English or Japanese
LCD Display: Backlit Monochrome LCD Display
Status LED: 3 LED Indicators per Port: Yellow(Power), Red (Fail) and Green (Pass)
Control Panel: 4 push buttons (up, down, OK, ESC)
Features: Copy Modes: Quick Copy (Systems & Files): Supports Windows, Mac and Linux.
Whole Media Copy: Copies bit-by-bit regardless of format and data type.
Compare Function Bit-by-bit data comparison
Sanitization Modes: Quick Erase, Full Erase, and DoD Erase
Compatibility:
Compatible Devices: USB1.1/2.0/3.0/3.1/3.2 devices and USB-HDDs
Compatible Devices (with required adapter): eUSB (USB DOM) 2.54mm and 2.00mm
Supported O/S: All (Windows, Mac, Linux, and other stand-alone systems)
Supported Formats:
  • Quick Copy: FAT16/32/64, Windows (NTFS), and Linux (Ext2/Ext3/Ext4), and Mac (HFS, HFS+, HFSX)
  • Whole Media Copy: All Formats, including proprietary formats
  • GPT, MBR, and Advanced Formats
Hardware Specifications: Working Temperature: 5°C ~ 45°C  (41°F ~ 113°F)
Storage Temperature: -20°C ~ 85°C (-4°F ~ 185°F)
Working Humidity: 20% ~ 80%
Storage Humidity: 5% ~ 95%
Certifications: FCC, CE, RoHS, MIL-STD810H
Power Supply: Power Adapter Input: 100-240VAC / 47-63Hz / 1.6A Max.
Power Adapter Output: 12VDC / 9A for UB910U3 (10-Ports)
Power Adapter Output: 12VDC / 12.5A for UB9XXU3 (20-Ports and Higher)
Each USB 3.0 Port supports up to 2A
Functions: Media Checking Tools: Diverse tools for verifying flash quality for bad sectors, capacity authenticity, and read/write speeds.
Do Format: Automatically detects and formats device(s) to either FAT16 or FAT32
Capacity Check: Verifies the maximum capacity available
Cal. CRC64: Calculates the CRC64 value from the source device.
A2 Fake Picker: Checks device(s) that contain fake capacities.
Burn-in Test : Set from 30 Minutes through 30 days for intensive media quality check.
Use Port 2 as Comparison Source: Reduces wear on a source device. Requires 2 exact source devices for this function to work.
Write Protect: Performs hardware-level write protection to connected device(s)
Log Report Management: Output and manage your log reports for internal records.

Frequently Asked Questions

What are the differences between "Quick" and "Whole Media" copy?

Quick Copy: (Function 7.2 - System and Files) Selectively copies only the data-containing areas within supported formats. It analyzes data formats, capacities, and locations. If the source data exceeds the target’s capacity, the copy fails.

Whole Media Copy: (Function 7.2 - Whole Media) Skips analysis and performs a full bit-by-bit duplication of the entire source. It’s slower but ensures maximum accuracy.

Why is the duplication process slow?

U-Reach flash duplicators support up to 33MB/sec. If you notice slow speeds, useFunction 6.2 Measure Speedto test the device. For example, if writing speed is 10MB/sec, 1GB will take ~2 minutes to duplicate.

What diagnostic tools are available for the flash duplicator?

  • Function 4: Media Check – Bit-by-bit check for bad sectors.
  • Function 6.2: Measure Speed – Measures read/write speed in 10 seconds.
  • Function 6.3: Capacity Check – Detects the true capacity to identify fake devices.

How can I ensure data duplication accuracy?

  • Use Function 6.8 Calc. Checksum to verify data source consistency.
  • Use Function 2 Compare for hardware-based bit-by-bit verification of target devices.

Why do I see a "No Update File" message during BIOS update?

  • Ensure the BIOS file is unzipped and not compressed.
  • Place the BIOS file in the root directory of the drive.
  • Try saving the file to another working device.
  • Redownload the BIOS file and disable interfering software.
  • Verify that the file matches your product model.

What causes immediate duplication failure after starting the copy process?

  • Make sure the source data does not exceed the target device’s capacity.
  • When duplicating NTFS sources, the target must be at least 1MB larger.
  • Verify the source using a PC to confirm no errors.
  • Ensure SD cards are not locked if they’re being used.
