MTC Series HDD/SSD Daisy Chain High Speed Duplicator and Sanitizer

$5,900.00 CAD
$5,900.00 CAD
SKU: URCAMTC1500F
MTC Series HDD/SSD Daisy Chain High Speed Duplicator and Sanitizer image 1 product photo
$5,900.00 CAD
$5,900.00 CAD

The Ultimate High-Speed Data Duplication and Sanitization Solution:

MT/MTC Series Duplicators The MT/MTC series is an ultra-high speed duplicator and each SATA port is independent. That's why no matter how many targets are running it’ll provide the same performance speed, far beyond PC-based duplicator capabilities.

The MT/MTC series device duplicator is specially designed for professional use. The smart Quick Copy mode supports FAT16/32/64, Windows NTFS, Linux ext2/3/4, and Mac HFS/HFS+/HFSX formats which can copy only data contained area that provides increased production efficiency. Furthermore, the innovative interface design allows for effortless device swapping during operation, which reduces time and effort throughout repairing.

Complies with the U.S. Department of Defense's erasing standard (DoD 5220.22 M) and Secure Erase (NIST 800-88). It is important to ensure that data contained on discarded devices cannot be retrieved and can be securely transferred.

Features

    • The 1 to 15 Duplicator performs speed transfers up to 15 GB per minute.
    • The 1 to 16 Duplicator performs speed transfers up to 9 GB per minute.
    • Systems & files code mode supports Windows(FAT16/32/64, NTFS), Linux(ext2/ext3/ext4), Mac(HFS, HFS+, HFSX.)
    • Data Sanitization: quick erase, full erase, secure erase, and DoD erase.
    • Open-platform Design supports multi-interface HDD/SSD.
    • Real-time PC monitoring
    • Supports 2.5", 3.5" SATA HDD, SSD and IDE HDD via IDE_SATA convertor (1 piece IDE to SATA adapter-TB1529 included)
    • Log report management records all task details for better production management.
    • "Daisy-Chain" technology makes production more efficient as the number of connections increase(Patent No.: US 9,349,408 B2)



Overview

Intelligent Duplication Modes for Optimal Performance
The MT/MTC series offers a diverse range of duplication modes, allowing users to select the most suitable mode based on their specific application demands. These intelligent duplication modes optimize the duplication process, ensuring efficient and accurate data replication.



Illustration of Copy Modes
The MT/MTC series duplicators employ various copy modes to facilitate data duplication. The areas containing data are marked in blue, while the areas being copied are marked in red. The duplication time depends on the speed supported by the hard drive's controller chip.



Superior Speed and Performance
The MT/MTC series duplicators excel in high-speed duplication, ensuring impeccable performance and efficiency. With speeds of up to 15 GB per minute for the 1 to 15 duplicator and up to 9 GB per minute for the 1 to 16 duplicator, these devices are ideal for manufacturers and professionals who demand swift and reliable data duplication.



Daisy Chain Technology
The MT/MTC series features innovative Daisy-Chain technology, allowing for efficient replication of multiple targets. By interconnecting the duplicators, production becomes more streamlined as the number of connections increases. This patented technology simplifies the duplication process and saves valuable time and effort.

    • Daisy-Chain Connector - Mini-SAS (SFF-8088)
    • Daisy-Chain technology - Patent No.: US 9,349,408 B2



High Compatibility

    • Quick copy mode supports Windows (FAT16/32/64), Linux (ext2/ext3/ext4), and Mac (HFS/HFS+/HFSX) formats.
    • Whole media copy mode supports all system and proprietary formats.
    • Supports various brands.
    • Designed to support 18TB+ capacities.
    • Supports MBR and GPT partitioning.



Advanced Data Sanitization for Data Security
Data security is paramount, and the MT/MTC series addresses this concern with its comprehensive data sanitization capabilities. The duplicators offer multiple sanitization methods, including quick erase, full erase, DoD erase (compliant with U.S. Department of Defense standards), and secure erase (accepted technique according to NIST 800-88). These methods ensure that data on discarded devices is irretrievable, providing robust data protection and compliance with industry regulations.



Open-Platform Design for Versatile Connectivity
The MT/MTC series features an open-platform design that supports multi-interface HDDs and SSDs. Whether you're working with SATA, USB, or other interfaces, these duplicators offer seamless connectivity and compatibility with various storage devices. The open-platform design eliminates compatibility concerns, providing professionals with the flexibility to work with different drive types and interface standards effortlessly.



Real-Time PC Monitoring for Enhanced Control
The MT/MTC series duplicators provide real-time PC monitoring, empowering professionals with complete control over the duplication process. Through the monitoring interface, users can track the status and progress of duplication tasks, ensuring smooth operation and efficient workflow management. Real-time PC monitoring enhances control and enables proactive management of duplication tasks.



Modular Design for Cost-Effective Ownership
The MT/MTC series incorporates a modular port design, which reduces downtime and enhances long-term ownership benefits. With modular ports, professionals can replace individual ports if needed, eliminating the need to replace the entire device in case of port failure. This cost-effective approach ensures minimal disruption to workflow and maximizes the value of your investment.



Comprehensive Log Report Management
The MT/MTC series duplicators offer comprehensive log report management, allowing for detailed task tracking and production control. The log management system records essential details for each port, including serial numbers and source device flow. With detailed log reports, professionals can optimize their workflow, identify potential bottlenecks, and enhance overall production management.

The MT/MTC series HDD/SSD Daisy-Chain High-Speed Duplicator and Sanitizer 1-15 are the ultimate solutions for professional data duplication and sanitization needs. With their exceptional performance, intelligent features, and comprehensive compatibility, these duplicators empower professionals to replicate and protect their data with unmatched efficiency and reliability. Whether you need to duplicate large volumes of data or securely erase sensitive information, the MT/MTC series delivers outstanding results. Invest in the MT/MTC series today and experience the future of data duplication and sanitization.


General:
Model: MTC1500F
Target: 1:15
Features:
Operating Type: Stand-alone, FPGA-based operation (Non PC-based system design)
Controller Design: Embedded controller is designed to support capacities over 18TB+.
Constant improvement supports latest market-available devices.
Patented Daisy-Chain Design: A scalable and modular system enables expansive ownership flexibilities
Bandwidth Performance:
  • Speed transfers of up to 15.0GB/min. (250MB/sec.)
  • Dedicated bandwidth enables high-volume replications without speed degradation.
Event Log Management:
  • Records: operating durations, individual port copy progressions, connected device models, capacities, serial numbers, and PASS or FAIL results.
  • Device writing/reading speeds are recorded.
  • Log report files are generated through the front USB port and are saved to USB devices.
Real Time PC Monitoring: View live status for: writing/reading speeds, total capacity, current function progress per port.
Read Only Source Port: There are no options to disable this built-in feature and is integrated with all U-Reach duplicators.
Modular Cabling Design: Modular-designed ports effectively reduce downtime and is cost-effective for long-term ownership
Product Functions:
4 Copy Modes: Quick Copy (Data & System):Supports Windows, Mac, and Linux.
All Partitions: Users can skip HPA or unknown partitions.
Whole Device: Copies bit-by-bit from the master device
Percentage Copy: Users can set percentages of capacity to be copied
Compare (Verification): Bit-by-bit data comparison from the source device to target device(s).
7 Sanitization Modes:
  • Quick Erase
  • Full Erase (NIST 800-88)
  • Secure Erase (NIST 800-88)
  • DoD3 Pass (DoD 5220.22-M)
  • DoD3 Pass+Compare (DoD 5220.22-M)
  • DoD7 Pass [DoD 5220.22-M(ECE)]
  • Enhanced Secure Erase
Bad Sector Scan: Scans device for any bad sectors by reading and writing.
Thorough Sector Scan: Scans device for any bad sectors by reading and writing two times.
Skip Bad Sectors: Choose the number of bad sectors to skip.
Minimum Speed: Disable or set minimum threshold speed to drop the slowest device.
Check Source Minimum Speed: Allows user to enable or disable the source speed check
Unknown Format: Choose to copy or skip unknown formats.
Erase Source Port: Enable or disable source port from being erased
Device Power-up: Choose time to wait for the device to power up prior to copy, erase, etc.
Device Power-down: Choose time to wait for the device to power down prior to disconnection.
Scroll Lock: Disable or enable ▲ and ▼ buttons on the control panel.
HPA Copy Modes: Allows user to choose various HPA replication methods
Clear HPA at Erase: Keep or clear HPA settings during sanitization process.
Language: English or Japanese.
Transfer Modes: Allows user to select the transfer rate.
Log Manager: Manage and export log reports.
Compatibilities:
Compatible Devices: 1.8"/2.5"/3.5" eSATA/SATA HDDs and SDDs
Compatible Devices (Requires Optional Adapters): 1.8” ZIF HDD/SSD, 2.5"/3.5” IDE, iVDR, mSATA SSD, MicroSATA, M.2 (NGFF), CFast, and Panasonic CF-29 through CF-74.
Supported Formats:
  • Quick Copy Function: FAT16/32/64, Windows (NTFS), Linux (Ext2/Ext3/Ext4), and Mac (HFS, HFS+, HFSX).
  • Whole Device Copy Function: All Formats, including proprietary formats.
  • GPT, MBR, and Advanced Formats.
Supported O/S: All (Windows, Mac, Linux, and other proprietary systems).
Hardware
Specification:
LCD Display: Backlit Monochrome LCD Display
LEDs: 3 LED Indicators per Port: Yellow (Power), Green (Pass), and Red (Fail)
Control Panel: 4 Push Buttons(▲, ▼, OK, ESC)
Power Requirements: Universal Power: 115VAC or 230VAC, 50/60Hz
Operational Temperature: 0°C ~ 60°C (32°F ~ 140°F)
Non-operational Temperature: -20°C ~ 85°C (-4°F ~ 185°F)
Humidity: Operating: 20% ~ 80%, non-condensing
Non-operating: 5% to 95%, non-condensing
Product Dimensions:
  • MTC1500F – 740 mm x 520 mm x 380 mm (29.1 in. x 20.5 in. x 15 in.)
Product Weight:
  • MTC1500F – 13.1 kg (28.9 lbs.)
Certifications: FCC, CE, RoHS and Reach

Frequently Asked Questions

What is the maximum data transfer speed of the MT/MTC series?

The MT/MTC series offers impressive speed transfers, with the 1 to 15 duplicator achieving up to 15 GB per minute and the 1 to 16 duplicator reaching up to 9 GB per minute. These high-speed transfers ensure swift and efficient data replication.

Which file systems are supported by the MT/MTC series?

The MT/MTC series supports a wide range of file systems, including Windows (FAT16/32/64, NTFS), Linux (ext2/ext3/ext4), and Mac (HFS, HFS+, HFSX). This extensive compatibility ensures seamless integration with different operating environments and file systems.

Can the MT/MTC series handle different types of storage devices?

Absolutely! The MT/MTC series supports 2.5" and 3.5" SATA HDDs, SSDs, and even IDE HDDs via the IDE_SATA converter, providing versatility for various storage devices.

Does the MT/MTC series offer data sanitization capabilities?

Yes, the MT/MTC series provides advanced data sanitization features, including quick erase, full erase, DoD erase (compliant with U.S. Department of Defense standards), and secure erase (accepted technique according to NIST 800-88). These methods ensure secure and irreversible data erasure.

Is the MT/MTC series compatible with different interfaces?

Yes, the MT/MTC series features an open-platform design that supports multi-interface HDDs and SSDs. Whether you're working with SATA, USB, or other interfaces, the MT/MTC series ensures seamless connectivity and compatibility.

Can I monitor the progress and details of each duplication task?

Certainly! The MT/MTC series provides comprehensive log report management, recording all task details for enhanced production control. By accessing the log reports, professionals can monitor the progress and performance of each duplication task, optimizing workflow and efficiency.
